58% reduction in emergency main breaks over 18 months

Background

Sonoran Metro Water is a municipal water utility serving approximately 47,000 residential and commercial connections across a rapidly growing suburb of greater Phoenix, Arizona. The utility's distribution system includes approximately 280 miles of pipe, with 38% of that network consisting of unlined cast iron mains installed between 1958 and 1977.

By 2024, the utility was responding to an average of 48 emergency main breaks per year — a number that had increased by 22% over the previous five years as the aging cast iron segments deteriorated under thermal cycling stress and increased system demand pressures.

The challenge

The utility's operations team had developed an informal sense of which neighborhoods experienced breaks most frequently, but had no systematic way to prioritize capital replacement across the entire network. Each year's capital budget requested by operations leadership was effectively an educated guess — and the utilities commission had grown skeptical of requests without quantitative backing.

Additionally, an EPA review in early 2025 flagged the utility's distribution-level water quality monitoring as insufficient under updated Lead and Copper Rule monitoring requirements, creating a parallel compliance urgency.

The Watsynq deployment

Watsynq initiated a 90-day paid pilot in April 2025. The onboarding process involved ingesting 26 years of break event records from the utility's CMMS, GIS pipe attribute data, and SCADA pressure historian going back to 2018. Eight inline WQ sensor nodes were installed at high-traffic junctions across the three pressure zones with the highest historical break frequency.

By the end of the 90-day pilot, the risk model had identified 22 pipe segments (totaling approximately 8.4 miles) with composite risk scores above 82 — and could demonstrate that those 22 segments accounted for 61% of all break events in the prior 36 months. This data became the foundation of a formal capital replacement recommendation to the utilities commission.

Results

The commission approved a 6% rate increase, structured to fund accelerated replacement of the 22 highest-risk segments over 18 months. Replacement work began in Q3 2025 and was completed in Q4 2025 for the top 12 segments.

By March 2026 — 18 months after pilot initiation — the utility's trailing-12-month emergency break count had fallen from 48 to 20 per year: a 58% reduction. The capital replacement investment totaled approximately $4.7M. Avoided emergency repair costs over the same period were independently calculated at $2.1M.

Beyond the headline numbers

The 58% break reduction figure captures the most visible outcome, but the changes to operational workflow that produced it are worth examining in more detail. Before the Watsynq deployment, the utility's operations team responded to breaks in a fundamentally reactive pattern: a customer call or SCADA pressure drop initiated a crew dispatch, the crew used portable acoustic detection equipment to locate the break, and excavation typically began within 4–6 hours of the initial alert.

After the first risk map was delivered, the operations team began a practice they hadn't used before: pre-positioning repair materials in corridors where the risk model showed elevated scores, during the weeks leading into the high-risk summer-to-monsoon transition period. The three highest-risk segments in the initial risk map — all 1960s-era unlined cast iron mains in an older commercial corridor — had repair fittings, bypass pipe sections, and compacted bedding material staged in the utility's nearest yard. When Segment 3 on that list broke in late June 2025, the repair crew was on site with materials in 90 minutes rather than the 3.5-hour average for an unplanned emergency response. The service restoration time dropped from a historical average of 8 hours for that corridor type to 4.2 hours.

That operational adaptation — using the risk map not just for capital planning but for operational readiness staging — was developed by the utility's operations superintendent without a formal process change. It's the kind of practical application that doesn't appear in a pilot deliverable document but contributes directly to service reliability outcomes.

Water quality compliance as a co-benefit

The eight WQ sensor nodes installed during the pilot were initially positioned to support the LCRR compliance gaps identified in the EPA review. As the system collected data across the three priority pressure zones, the chlorine residual monitoring revealed a distribution pattern that the utility's engineering team had suspected but not been able to quantify: the residential zone at the far end of the distribution system — Zone 3 — was showing chlorine residual values below 0.2 mg/L at several monitoring points during overnight low-demand periods. The extended water age in that zone's dead-end mains, combined with the warm ambient temperatures typical of Phoenix summers, was driving chlorine demand faster than the modeling had predicted.

The WQ data prompted the utility to adjust its automated flushing program for Zone 3 — extending the flushing frequency and duration during peak summer months. The chlorine residual in the affected zone improved to consistent compliance levels within eight weeks of the adjustment. Without continuous monitoring at the endpoint nodes, the compliance issue would likely not have been detected until the next routine compliance sampling event, potentially six months later.

The rate case narrative

The 6% rate increase approved by the utilities commission in Q2 2025 was structured specifically around the capital replacement program identified by the Watsynq risk analysis. The commission presentation included the risk score ranking with the 22 highest-risk segments identified, the historical break frequency correlation (those 22 segments accounted for 61% of all breaks in the prior 36 months), and a five-year capital replacement schedule with projected break rate trajectory under three scenarios: no action, partial replacement, and full replacement of the top 22 segments.

"We've requested infrastructure investment from the commission before. What was different this time was the data. We could show them exactly which pipe, why it was at risk, and what the replacement would prevent. That changed the conversation from 'how much do you need' to 'when do we start.'"

— Director of Infrastructure Operations, Sonoran Metro Water Authority

The commission's approval was unanimous — the first unanimous infrastructure capital vote in three years. The data-backed presentation eliminated the uncertainty that typically produces commissioner skepticism about reactive, intuition-based capital requests.
